6mm Dia 4-Flute Metric End Mill 20mm LOC, 6mm Shank, 63mm OAL

4 Flute Standard Length Metric Compression Router

PREVIEW AND DIAGRAM (MCR-402)

Specifications

Cutting Dia 0.2362″
Flute Len 0.7874″
Shank Dia 0.2362″
Overall Len 2.4803″
Upshear Len 0.1969″

Tolerances

Cutting Diameter−0.0254/−0.0762 mm
Length of Cut+0.762/+1.524 mm
Shank Diameter−0.0025/−0.0051 mm
Overall Length±.060 mm

Catalog

Catalog Page 37

Speed & Feeds

MaterialSFM1/4"5/16"3/8"1/2"5/8"3/4"1"
MaterialSFMRPMCLPTRPMCLPTRPMCLPTRPMCLPTRPMCLPTRPMCLPTRPMCLPT
G10 Fiberglass/Polyester1000152800.0034122240.0043101870.005176400.006861120.008550930.010238200.0136
Graphite1000152800.0064122240.0080101870.009676400.012861120.016050930.019238200.0256
Graphite Fiber/Expoxy800122240.002097790.002581490.003061120.004048900.005040750.006030560.0080
Plastics1300198640.0064158910.0080132430.009699320.012879460.01666210.019249660.0256
